2012

JUST SOLD – Cessna Citation XLS+

SN 560-6120 – REG. #N224JW

2,100 NM

(3889.2 km) Maximum Range1

9

Maximum Capacity

441 KTAS

Maximum Cruise Speed


1 https://cessna.txtav.com/en/citation/xls

About this Aircraft

This 2012 Cessna Citation XLS+, serial number 6120, is currently owned and operated by a long-time Citation operator. The current owner acquired the aircraft in 2016 and is the second owner of this aircraft. Operated predominately in the US (with occasional trips to Canada), the aircraft is currently based in Redmond, Oregon and always hangared. As a result, this aircraft is cosmetically in great shape inside and out. The aircraft recently completed a 96 month inspection making this a turnkey opportunity.

  • Below average utilization for an aircraft this age
  • Airframe Rating is a 9 (above average)
  • Equipped with the standard Collins Proline 21 avionics package
  • Inerior layout is a 9-seat interior
  • Three axxes II Iridium satcom phone system plus the gogo wifi ATG4000

Range Map

What does 2,100 NM look like?

Range calculation from Seattle

2012

JUST SOLD – Cessna Citation XLS+

SN 560-6120 – REG. #N224JW

Cabin looking forward
Cabin Looking Aft
Forward Two-Place Divan
Interior Looking Forward at the Divan and Refreshment Center
Lavatory & Aft Belted Seat
Flight Deck

To learn more about this aircraft or to speak with a VanAllen Managing Director, contact us today.

contact us

AIRCRAFT SPECS

Genergal Infomation
MANUFACTURER & MODELCessna Citation XLS+
AIRCRAFT SERIAL NUMBER560-6120
DATE OF MANUFACTURESeptember 29, 2012
CURRENT REGISTRATION NUMBERN224JW
BASE LOCATIONRedmond, OR (KRDM)

Engine & APUENGINE #1ENGINE #2APU
MODELP&W PW545CP&W PW545CHoneywell RE100XL
SERIAL NUMBER(S)PCE-DF0245PCE-DF0246P-921
TOTAL HOURS SINCE NEW2,235.2 Hours2,235.2 Hours263.3 Hours
TOTAL CYCLES SINCE NEW2,462 Cycles2,462 Cycles640 Cycles
MAINTENANCE PROGRAM

Airframe Time & Cycles
TOTAL TIME SINCE NEW2,235.2 Hours (as of November 16, 2020)
TOTAL LANDINGS SINCE NEW2,462 Landings

Maintenance StatusINSPECTIONLAST COMPLETEDDUE NEXT
Document 1November 2020November 2021
Document 3November 2020May 2022
Document 6November 2020May 2024
Document 11November 2020May 2022
Document 16November 2020September 2028
Document 192,231.8 Hours2,532 Hours
Engine HSIN/A2,750 Hours

Equipment
Aircell ATG4000 WiFi
LED Cabin Lighting
77 Cu. Ft. Oxygen Bottle
Two (2) 110VAC Cabin Outlets
Two (2) 110VAC Cockpit Outlet
Fwd LH Refreshment Center w/ Tambour Doors, Additional Soda Storage & Pull-out Work Surface
Aft Vanity
Monorail Sunvisors
Locking Fuel Caps
External Servicable LAV
Aircell Axxess Phone w/ 3 Handsets
10.4” Video Monitor mounted in RH Fwd Cabinet
Two (2) Executive Tables & Two (2) Slimline Tables w/ Leather Inserts
Airshow 4000 Plus w/ Rosen Flight View Moving Map System
Aft Belted LH Side Facing Seat
Two (2) Flashlights
Tail Logo Lights

Avionics
Collins Pro Line 21 Avionics 4 Tube EFIS
Dual Collis AHC-3000 AHRS
Dual Collins ADC-3000 Air Data Computers
Dual Collins DCP-3310 Cursor Control Panels
Collins IFIS-5000 (Weather & Charts)
Collins TTR-4000 TCAS II
Dual Collins FMS-3000
Collins FMS Performance Database
WASS w/ FMS 4.0 Software & V Speeds
Dual Collins GPS-4000S
Dual Collins RTU-4000 Radio Tuning Units
Dual Collins NAV-4500 Navigation Receivers
Collins NAV-4000 w/ ADF
Dual Collins TDR-94D Mode S Transponders
Dual Collins DME-4000
XM Satellite Weather
AOA
Dual FSU 5010
Mark V EGPWS w/ RASS
Collins WXR-850 Turbulence Doppler Weather Radar
Jeppensen Electronic Charts Capability
Collins FGS w/ Emergency Decent Mode
Artex C406-N 3-Frequency ELT
L3 FA2100 Cockpit Voice Recorder
Provisions Collins KHF-1050 High Freq. Com w/ SELCAL
Cockpit Speaker Mute Switch
Smoke Goggles
DBU-5000 USB Data Loader
Collins ALT-4000 Radio Altimeter

Connectivity
HIGH SPEED INTERNETGogo WiFi ATG4000
PHONE SYSTEMAircell Axxess II Iridium Satcom

Interior
NUMBER OF PASSENGERS9 Passengers
GALLEY LOCATIONForward Aircraft / Entryway Section
INTERIOR CONFIGURATIONFour (4) Place Center Club Configuration
Two (2) Forward-Facing Aft seats
One (1) Forward Two-Place Divan (located across from the entry way)
One (1) Left-Hand, Side-Facing seat (located across from the Lav) serves as the ninth seat

Exterior
BASE PAINT COLOR(S)Overall Snow White with Ming Blue Metallic
STRIPE COLOR(S)Black Laquer and Platinum Accent
LAST PAINTED DATE2012, Original Paint

Additional Amenities
LH REFRESHMENT CENTERIncludes the master switch panel, heated MAPCO, drip pan, pull-out work surface, drink storage, storage cabinets, and catering tray storage.
RH FORWARD MAIN STORAGEContains storage with several shelves, and the Rosen 10.4” entertainment display and light switch panel.

Weight & Balance
AIRCRAFT EMPTY WEIGHT12,406.8 lbs
LAST WEIGHEDMay 3, 2019
REWEIGH DUE (IF UNDER PART 135)N/A
